Heavy duty shelf

Bearing capacity: 500KG-8000KG per floor, customized as required
Picking method: forklift access
Structural appearance: the main body is composed of a beam and a column piece. The column is a diamond shaped hole. The main frame and subframe are combined and connected. The plug-in assembly structure. The unit cargo height is adjusted up and down at a pitch of 75mm. The normal color is column royal blue, and the beam is orange red
Channel requirements: the forklift channel is determined according to the turning radius of the forklift and the size of the pallet, usually 3.2-3.5m
Warehouse requirements: applicable to warehouse height of more than 3m and shelf height of up to 15m
Advantages: large bearing capacity, simple structure, convenient disassembly and assembly, and convenient goods picking
Scope of application: suitable for most warehouses or product goods
Supporting accessories: guardrail, corner guard, partition and steel plate
Product extension: double deep shelf, narrow roadway shelf
